3M Plate Mounting Tape, Matched to Your Plate

Halftones filling in, weak solids, lifting edges. The fix is often the tape under the plate. Find the exact 3M Cushion-Mount Plus part number in three clicks.

The 3M Combination Printing Spectrum

← Softer: processFirmer: solids →
8color-coded series
15 & 20 milnarrow and wide web
Up to 54"plus custom widths
Same dayshipping on in-stock rolls
01 · Tape Finder

Find Your Exact 3M Tape

Three questions. Watch your part number build on the right, then get a quote on the exact width you need.

1

What do you run?

3M builds 15 mil for narrow web and 20 mil for wide and mid web.

2

What's on the plate?

This picks the foam. Softer protects fine dots. Firmer lays down solid ink.

Know your series? Tap it.Softer ← → Firmer
3

How should it hold your plates?

We start you on EH. Extra plate-side grip keeps edges down at press speed. Change it anytime.

02 · The Lineup

The 8 Cushion-Mount Plus Series

Softest to firmest. 3M makes every series in 15 and 20 mil with EH, L, or E adhesive. Tap a part number for widths and a quote.

03 · Part Numbers

Every 3M Part Number We Carry

The full lineup in one chart. Don't see it? Ask. We can usually source it.

Stocked widths vary by part number, up to 54". Custom widths available. Swipe the chart on mobile.

04 · Decoder

How to Read a 3M Part Number

EAdhesive family
13Series and color
15Thickness in mils
HMakes it EH: high adhesion

E1315H is a 13 Series (yellow, Medium Soft), 15 mil EH tape with high plate-side adhesion. Every version uses 3M's air-release liner, so trapped air bleeds out instead of bubbling under the plate.

EH

Easy Mount, High Adhesion

Our go-to recommendation. 3M's air-release liner plus more grip on the plate side, so edges stay down on cylinders as small as 2" in diameter.

L

Less Removal Force

Air release plus easy, clean plate removal. Less stress on plates at demount while still resisting lift on press.

E

Easy Mount, Standard

Air release with standard plate-side adhesion. Suited to large cylinders and forgiving jobs.

05 · Troubleshooting

Print Problem? Start With the Tape

Six common pressroom issues and the tape change that usually fixes them.

Still stuck?

Tell us your web width, what's on the plate, and what you're seeing on press. A Q360 tape specialist will point you to the right 3M part.

Call 609-646-2212

or send us a message

Go softer

Highlights and halftones filling in

Move one step toward Process. A softer foam absorbs impression so fine dots don't spread.

Go firmer

Solids weak, mottled, or pinholed

Move one step toward Firm. A denser foam puts more pressure behind solid ink coverage.

Switch to EH

Plate edges lifting

Higher plate-side adhesion holds edges on small cylinders and tight wraps. Keep the same series so print doesn't change.

Switch to L

Plates tearing at demount

Less removal force lets plates come off clean, which protects plates you plan to reuse.

Mount center out

Bubbles under the plate

Every EH, L, and E version is air release. Mount from the center out and the channels do the rest.

Prime it

Tape won't stay on the sleeve

3M Tape Primer 94 improves tape adhesion to hard-to-bond surfaces like PE, PP, and ABS.

06 · Beyond Mounting Tape

Everything Else 3M for the Pressroom

Why converters buy 3M from Q360

Genuine 3M through an authorized channel, a deep shelf, and a team that speaks flexo.

Download the 3M Guide (PDF)
All 8

Series stocked in both 15 and 20 mil, across EH, L, and E adhesives.

Same day

Shipping on in-stock rolls, with custom widths when your job needs them.

250+ years

Of combined flexo experience. Tell us what you print and we'll match the tape.

One PO

Tape, blades, anilox, parts, and equipment from one pressroom partner.

07 · FAQ

3M Plate Mounting Tape FAQ

Quick answers

The questions converters ask us most. Have one we didn't cover? Ask and we'll get you an answer fast.

Ask a Specialist
Which 3M tape is best for halftones and process work?

Go soft. The 11 Series (tan, Process) is 3M's choice when tone reproduction matters most. The 12 Series (orange, Light) and 19 Series (pink, Light Medium) handle process-heavy combination work with a little more support for solids.

Which 3M tape is best for solids and line work?

Go firm. The 18 Series (blue, Firm) is built for solids and line with minimal tone. The 17 Series (teal, Medium Firm) and 15 Series (purple, Medium) add room for tone and fine reverses.

What if I print solids and halftones on the same plate?

Start with the 10 Series (white, Standard), made for jobs where solids and process are equally important. If dots fill in, step softer to the 13 Series. If solids look weak, step firmer to the 15 Series.

Should I use 15 mil or 20 mil?

3M designs 15 mil for narrow web and 20 mil for wide and mid web. The right caliper is the one your cylinder or sleeve and plate are set up for, so match what you run today. 3M lists 15 mil at a .015" application thickness (.017" manufacturing target) and 20 mil at .020" (.022" target).

What's the difference between EH, L, and E?

All three are air release. EH adds plate-side adhesion to hold edges on cylinders as small as 2", and it's what we recommend for most jobs. L lowers removal force so plates come off easily without damage. E is standard plate-side adhesion for large cylinders and forgiving jobs.

What do the tape colors mean?

3M color codes each series by firmness: tan (11), orange (12), pink (19), yellow (13), white (10), purple (15), teal (17), and blue (18), softest to firmest. Operators can tell what's mounted at a glance.

Do you cut custom widths?

Yes. We stock a range of widths on every part number, up to 54", and we offer custom widths. Request a quote with the width you need.

How fast does it ship?

In-stock rolls ship the same day. For custom widths or large orders, we'll confirm timing with your quote.

How do I reorder the tape I already use?

Type your part number in the search at the top of this page to go straight to it, or call 609-646-2212 and we'll pull up what you ordered last time.

Tell Us What You Print. We'll Match the Tape.

Send your web width, what's on the plate, and what's going wrong on press. A Q360 tape specialist will come back with the right 3M part number and a quote.
