Mark Andy E5 13" 6 Color Press

SKU:36-687

Mark Andy E5 13" 6 Color Press:
Age: 2022
Web width: 330mm
Servo unwind
Vetaphone corona and plasma treater
Vacuum web cleaner
6 x servo driven flexo print stations with load and lock inking
6 x GEW Leo LED dryers
6 x chill rolls
Automatic register control
Full press rail system with options mounted:
Web turner bar
Cold foil - UV lamination unwind (servo)
Cold foil - UV lamination rewind (servo)
2 x servo rotary die stations (1 x Wink SmartGap unit)
Magnetic cylinder hoist and crane
1 Waste rewind
Slitting station
Sheeting station
2 x servo rewinds
Video inspection camera
All print tooling available

ABG SGTR330 Turret Rewinder:
Rail mounted to move in and out of line with the press
Age: 2022
Web width: 330mm
Infeed encoder
Infeed lane divider
Glueless core cynch mechanism
4 x servo driven rewind shafts
Glueless roll closing with label applicator
Automatic core loading with snorkel feed
Automatic core positioning for accurate positioning on air shaft
Automatic core eject
Touchscreen HMI with job store feature
Mark Andy E5 13" 6 Color Press

Mark Andy E5 13" 6 Color Press
